RQ3 Well-Type Carburizing Furnace: A Sharpened Tool for Core Component Upgrades

   In the manufacturing of critical components such as gears, bearings, and transmission shafts, carburizing heat treatment is a core process for enhancing surface hardness and wear resistance. The RQ3 seriesWell-type Carburizing Furnace, with its unique technical advantages, is becoming the ‘secret weapon’ for more and more enterprises looking to improve quality and efficiency.

  Why Choose the RQ3 Well-Type Furnace? Four Major Advantages:

Deeper and More Uniform Carburization

The vertical hoisting structure, combined with a powerful fan circulation system, ensures 360° coverage of the workpiece by the furnace temperature and carburizing atmosphere, leaving no dead corners. Even when processing long shafts or irregularly shaped parts, consistent carburized layer depth is achieved, avoiding soft spots and deformation.

Intelligent Carbon Potential Control

Equipped with a high-precision oxygen probe and intelligent control system, it monitors and adjusts carbon potential in real-time (with ±0.05% accuracy).

Energy-Saving and Enhanced Sealing

The multi-layer fiber insulation and labyrinth seal design reduce heat loss by 30%, while effectively preventing air ingress. Improved atmosphere stability helps reduce enriched gas consumption, significantly decreasing the comprehensive energy consumption per furnace.

Automation Saves Labor

Optional automatic lifting platforms and material conveying chains enable automated loading, carburizing, and quenching processes. Workers are kept away from high-temperature areas, and production efficiency is increased by over 50%.

‘In the past, we always worried about uneven layer depth when carburizing gears. The controllable atmosphere technology of the RQ3Well-type Furnace  has completely solved this problem.’

   Professional Equipment Guarantee: Empowered by a Leading Domestic Manufacturer

As one of China’s important heat treatment equipment manufacturers,China-Europe industrial Furnace‘sRQ3seriesWell-type Carburizing Furnace  has been successfully applied in:

✅ Precision carburizing of automotive gears

✅ Strengthening of construction machinery bearings

✅ Deep treatment of wind power main shafts

Get Your Exclusive Carburizing Solution:

• Product Details: RQ3 Well-Type Carburizing Furnace Technical Parameters
• Company Website: www.furnace1992.com

• Contact Information: Wechat: +86-13615267218
• Whatsapp: +86-13615267218 Email: tina@furnace1992.com
• Parameter

  Model	Loading size (mm)	Loading capacity (kg)	Power, kWt	Heating zones, pcs.
  RN3-75-7	Ø600×900	450	75	1
  RJ3-90-7	Ø800×1200	1000	90	1
  RJ3-120-7	Ø1000×1500	2000	120	1
  RJ3-150-7	Ø1200×1800	3000	150	2

•
