Recently, our company successfully delivered a drop bottom furnace for aluminum solution heat treatment and vertical quenching to a client in Russia. This equipment features advanced energy-saving technology and stable performance, meeting the client’s high standards for aluminum alloy heat treatment processes.
This delivery marks another successful expansion for our company in the Russian market. The client highly praised the equipment’s manufacturing process and operational performance and expressed a desire to further deepen cooperation with our company.
Our company will continue to uphold the philosophy of ‘quality first, service foremost,’ constantly improving our products and service levels to provide more efficient and reliable industrial furnace solutions for global clients.
Technical Parameters
| 1.Furnace loading weight: 500 kg | 2. Loading basket (material frame) inner size (length × width × height): 1200×1000×1000 mm |
| 3. Heating power: 120 kW | 4. Quenching mechanism motor power: 11/7 kW |
| 5. Quenching transfer time: ≤12 sec | 6. Effective volume of quenching water tank: ≥10m³ |
| 7. Driving power of quenching tank: 3 kW | 8. Tank circulation pump drive power: 2.2 kW |
| 9. Power of water heaters: 24 kW (6*4 kW) | 10. Circulation fan power: 7.5 kW |
| 11. Power supply: 3 phase 380V 50 Hz | 12. Operating temperature range: 50-650°C |
| 13. Maximum temperature in the working area: 700 °C | 14. Temperature uniformity in the working area: ±5 °C |
| 15. Type of heaters: Ribbon type heater 0Cr25AL5 | 16. Furnace heating type: electric |
| 17. Accuracy of temperature control in the furnace chamber: 0,3 class | 18. Thermocouple: type “K” |
| 19. Number of temperature control zones: 1 | 20. Method of cooling the tank: in water |
| 21. Heating speed of empty furnace to 550°C: 1.5 hour | 22. Furnace body surface temperature: ≤35°C |
| 23. Stainless steel air guide cover plate and a circulation fan: must be do | 24. Packing in wooden boxes for control cabinets, fan, electric motors, spare parts |
