New Generation Drop Bottom Furnace for Aluminum Solution Heat Treatment and Vertical Quenching Successfully Applied

2025-09-24 11:12:18

  Recently, our company’s new generation of drop bottom furnace for Aluminum Solution Heat Treatment and Vertical Quenching has been officially put into application. This equipment is specially designed for Aluminum Solution Heat Treatment and Vertical Quenching processes, ensuring optimal Temperature Uniformity and Controlled Cooling Rate for workpieces under high-temperature conditions.

  The furnace adopts a Drop Bottom Quench Furnace structure. Through Microstructural Refinement, the equipment significantly improves the Mechanical Properties, Yield Strength, Hardness, Corrosion Resistance, and Fatigue Life of aluminum alloys.

  In addition, the system integrates Energy-Efficient Heat Treatment technology and an Automated Heat Treatment System, effectively reducing energy consumption and minimizing workpiece distortion, providing customers with more efficient, stable, and eco-friendly Aluminum Heat Treatment Solutions.

The successful application of this product marks a new milestone for our company in the field of Aluminum Heat Treatment, delivering greater value to global manufacturing clients.

Technical Parameters

No. Parameter Value
1 Rated Working Temperature 650℃
2 Rated Voltage 380V
3 Temperature Uniformity ±5℃
4 Temperature Control Accuracy 0.3 grade
5 Heating Power Resistance band heating 240KW (power adjustable/current limitable); Single zone power 90KW, usable independently
6 Material Basket Size 1600 × 1200 × 1200mm
7 Loading Capacity 1000Kg
8 Empty Furnace Heating Time 1.5h (550℃)
9 Fan Power 5.5Kw (2 units)
10 Furnace Shell Surface Temperature Rise ≤35℃ (excluding hot spots)
11 Quenching Transfer Time ≤15S
12 Effective Volume of Quenching Water Tank ≥30m³
13 Quenching Liquid Temperature Room temperature
14 Water Tank Heating Method Configured as needed; not configured for this furnace temporarily
15 Agitator Power Configured as needed; not configured for this furnace temporarily
16 Loading Cart Movement Manual push
17 Quenching Mechanism Motor Power 17/11Kw; Lowering rope speed: 16/32 m/min
18 Number of Heating Zones 1 zone
