Advanced Drop-Bottom Furnaces Improve Aluminum Heat Treatment Efficiency and Uniformity

1

Rated Working Temperature

650℃

2

Rated Voltage

380V

3

Temperature Uniformity

±5℃

4

Temperature Control Accuracy

Grade 0.3

5

Heating Power

Resistance band heating 240KW (power adjustable and current limitable), single-zone power 80KW, can be used independently

6

Basket Inner Dimensions

1600 × 1200 × 1200mm

7

Loading Capacity

1000Kg

8

Empty Furnace Heating Time

1.5h (to 550℃)

9

Fan Power

5.5Kw (2 units)

10

Furnace Shell Surface Temp. Rise

≤35℃ (excluding hot spots)

11

Quenching Transfer Time

≤15S

12

Quenching Water Tank Effective Volume

≥30m³

13

Quenching Liquid Temperature

Room temperature

14

Water Tank Heating Method

Configured as required; not configured for this furnace

15

Agitator Power

Configured as required; not configured for this furnace

16

Loading Cart Movement

Manual push

17

Quenching Mechanism Motor Power

17/11Kw (Descent rope speed: 16/32 meters/min)

18

Number of Heating Zones

3 zones
