Our company successfully delivered the forklift type resistance furnace heat treatment production line

2025-11-07 09:17:03

  Recently, our company successfully delivered a forklift-type resistance furnace heat treatment production line to a customer in Anhui. The production line includes a heating furnace, a tempering furnace, a loading/unloading trolley, and a smart control system. The customer provided their own material platforms and trays.

  This production line boasts a reasonable structure, convenient operation, precise temperature control, and high energy efficiency. It enables the efficient heating and tempering of workpieces, significantly boosting production efficiency and product quality.

  The smooth delivery of this project not only demonstrates our company’s R&D and manufacturing capabilities in the field of heat treatment equipment but also strengthens our cooperative relationship with the Anhui customer. In the future, we will continue to uphold the principle of ‘winning trust with quality and promoting development with service,’ providing professional and efficient heat treatment solutions to more customers.

Technical Specifications

No. Name Heating Furnace (Nitrogen-protected) Tempering Furnace
1 Equipment Model RX3-420-12 RX3-240-7
2 Internal Working Dimensions (W×L×H) 3.2m×2m×1m 3.2m×2m×1m
3 Furnace Opening Dimensions (W×H) 3.4m×2.5m 3.4m×2.5m
4 Furnace Type Box Furnace Box Furnace
5 Rated Power 420kw±10% 240kw±10%
6 Temperature Control Zones 3 2
7 Max. Loading Capacity 10 tons/furnace (including tray) 10 tons/furnace (including tray)
8 Rated Temperature 1200℃ 750℃
9 Furnace Temperature Uniformity ≤±8℃ ≤±5℃
10 Power Supply 380V 50Hz 3-phase 380V 50Hz 3-phase
11 Furnace Body Refractory Material Insulation Layer: 1260 Fiber
Fireproof Layer: Zirconia Fiber		 Insulation Layer: 1140 Fiber
Fireproof Layer: High-purity Fiber
12 Furnace Body Refractory Thickness 350mm 240mm
13 Control Point Temperature Difference ≤ ±1℃ ≤ ±1℃
14 Heating Rate 10-200℃/h (adjustable) 10-200℃/h (adjustable)
15 Furnace Body Outer Wall Temperature Rise Sides: +30℃, Top: +40℃ Sides: +30℃, Top: +40℃
16 Temperature Control Method Yudian AI516P + Touch Screen Control + PLC Yudian AI516P + Touch Screen Control + PLC
17 Furnace Door Lifting Speed: approx. 6m/min.
Lifting with inclined block compression + cylinder compression		 Top-mounted electric hoist drive
